SPECIFICATIONS

 ES250ES350
Overall length4900mm4900mm
Overall width1820mm1820mm
Overall height1450mm1450mm
Wheelbase2820mm2820mm
TreadFront: 1590mm

Rear: 1575mm
Front: 1590mm

Rear: 1575mm
Curb weight1575-1610kg1640-1685kg
Gross vehicle weight2100kg2130kg
 ES250ES350
SuspensionFront: MacPherson strut type

Rear: Dual-link strut type
Front: MacPherson strut type

Rear: Dual-link strut type
Steering SystemElectric Power SteeringElectric Power Steering
BrakesFront: 296mm ventilated discs

Rear: 281mm discs
Front: 328mm ventilated discs

Rear: 281mm discs
Minimum turning radius5.7m5.7m
Fuel Tank65 liters65 liters
Tires215/55R17215/55R17
  ES250 ES350
Piston Displacement 2.5-liter 3.5-liter
Cylinders 4 Cylinder, Twin Cam 24-valve V6 Four Cam 24-valve
Horsepower at RPM 181HP/6000rpm 272HP/6200rpm
Transmission 6-Speed Electronically
Controlled Transmission
6-Speed Electronically
Controlled Transmission
Brakes Front: 296mm ventilated discs

Rear: 281mm discs
Front: 328mm ventilated discs

Rear: 281mm discs
Tires 215/55R17 215/55R17
 ES250ES350
Piston Displacement2.5-liter3.5-liter
Cylinders4 Cylinder, Twin Cam 24-valveV6 Four Cam 24-valve
Horsepower at RPM181HP/6000rpm272HP/6200rpm
Transmission6-Speed Electronically
Controlled Transmission
6-Speed Electronically
Controlled Transmission
BrakesFront: 296mm ventilated discs

Rear: 281mm discs
Front: 328mm ventilated discs

Rear: 281mm discs
Tires215/55R17215/55R17
  • DIMENSIONS
    • ES250
      Overall length 4900mm
      Overall width 1820mm
      Overall height 1450mm
      Wheelbase 2820mm
      Tread Front: 1590mmRear: 1575mm
      Curb weight 1575-1610kg
      Gross vehicle weight 2100kg
    • ES350
      Overall length 4900mm
      Overall width 1820mm
      Overall height 1450mm
      Wheelbase 2820mm
      Tread Front: 1590mmRear: 1575mm
      Curb weight 1640-1685kg
      Gross vehicle weight 2130kg
  • CHASSIS
    • ES250
      Suspension Front: MacPherson strut typeRear: Dual-link strut type
      Steering System Electric Power Steering
      Brakes Front: 296mm ventilated discsRear: 281mm discs
      Minimum turning radius 5.7m
      Fuel Tank 65 liters
      Tires 215/55R17
    • ES350
      Suspension Front: MacPherson strut typeRear: Dual-link strut type
      Steering System Electric Power Steering
      Brakes Front: 328mm ventilated discsRear: 281mm discs
      Minimum turning radius 5.7m
      Fuel Tank 65 liters
      Tires 215/55R17
  • KEY SPECS
    • ES250
      Piston Displacement 2.5-liter
      Cylinders 4 Cylinder, Twin Cam 24-valve
      Horsepower at RPM 181HP/6000rpm
      Transmission 6-Speed Electronically Controlled Transmission
      Brakes Front: 296mm ventilated discs Rear: 281mm discs
      Tires 215/55R17
    • ES350
      Piston Displacement 3.5-liter
      Cylinders V6 Four Cam 24-valve
      Horsepower at RPM 272HP/6200rpm
      Transmission 6-Speed Electronically Controlled Transmission
      Brakes Front: 328mm ventilated discs Rear: 281mm discs
      Tires 215/55R17
  • ENGINE
    • ES250
      Piston Displacement 2.5-liter
      Cylinders 4 Cylinder, Twin Cam 24-valve
      Horsepower at RPM 181HP/6000rpm
      Transmission 6-Speed ElectronicallyControlled Transmission
      Brakes Front: 296mm ventilated discsRear: 281mm discs
      Tires 215/55R17
    • ES350
      Piston Displacement 3.5-liter
      Cylinders V6 Four Cam 24-valve
      Horsepower at RPM 272HP/6200rpm
      Transmission 6-Speed ElectronicallyControlled Transmission
      Brakes Front: 328mm ventilated discsRear: 281mm discs
      Tires 215/55R17
